VIPA FM 050-1BB30 8DO-24VDC
| SPECIFICATIONS | |
|---|---|
| Features | 2x Counter 32 Bit (AB) DC 24 VUp to 400 kHz |
| Current consumption from backplane bus | 75 mA |
| Power loss | 0.9 W |
| Number of inputs | 4 |
| Cable length, shielded | 100 m |
| Cable length, unshielded | – |
| Rated load voltage | DC 20.4…28.8 V |
| Reverse polarity protection of rated load voltage | – |
| Current consumption from load voltage L+ (without load) | 15 mA |
| Rated value | DC 20.4…28.8 V |
| Input voltage for signal “0” | DC 0…5 V |
| Input voltage for signal “1” | DC 15…28.8 V |
| Input voltage hysteresis | – |
| Signal logic input | – |
| Frequency range | – |
| Input resistance | – |
| Input current for signal “1” | 3 mA |
| Connection of Two-Wire-BEROs possible | |
| Max. permissible BERO quiescent current | 0.5 mA |
| Input delay of “0” to “1” | 0.8 µs |
| Input delay of “1” to “0” | 0.8 µs |
| Number of simultaneously utilizable inputs horizontal configuration | 4 |
| Number of simultaneously utilizable inputs vertical configuration | 4 |
| Input characteristic curve | IEC 61131-2, type 1 |
| Initial data size | 12 Byte |
| Number of counters | 2 |
| Counter width | 32 Bit |
| Maximum input frequency | 100 kHz |
| Maximum count frequency | 400 kHz |
| Mode incremental encoder | + |
| Mode pulse / direction | + |
| Mode pulse | – |
| Mode frequency counter | – |
| Mode period measurement | – |
| Gate input available | – |
| Latch input available | – |
| Reset input available | – |
| Counter output available | – |
