Series 328
Operating principle Reflection principle
Operating range 0.02 … 4.5 m, With reflector TK(S) 100×100
Operating range limit 0.02 … 6 m, With reflector TK(S) 100×100
Light source LED, Red
Protective circuit Polarity reversal protectionShort circuit protected
Supply voltage UB 10 … 30 V, DC, Incl. residual ripple
Residual ripple 0 … 15 %, From UB
Open-circuit current 0 … 20 mA
Number of digital switching outputs 2 Piece(s)
Switching element Transistor, PNP
Switching principle Light switching
Switching element Transistor, PNP
Switching principle Dark switching
Switching frequency 500 Hz
Response time 1 ms
Type of connection Connector
Thread size M12
Material Plastic
No. of pins 4 -pin
Thread size M18 x 1 mm
Dimension (Ø x L) 18 mm x 46 mm
Housing material PlasticStainless steel
Stainless steel housing V2A
Plastic housing ABS
Lens cover material Plastic
Net weight 20 g
Operational controls Teach button
Ambient temperature, operation -40 … 60 °C
