SCHMERSAL BNS 120-02Z
SCHMERSAL MAGNETIC SAFETY SENSOR
- Thermoplastic enclosure
- Suitable for food processing industry only in combination with BP 15 SS
- Particularly large switching distance
- Ø M12
- Long life
- no mechanical wear
- Insensitive to transverse misalignment
- Insensitive to soiling
- uncodiert, verdeckter Einbau gem. ISO 14119
| SPECIFICATIONS | |
|---|---|
| regulations | BG-GS-ET-14EN IEC 60947-5-3 |
| Coding level according to EN ISO 14119 | none |
| working principle | magnetic |
| Installation conditions (mechanical) | quasibündig |
| Material of the housing | Plastic, glass fiber reinforced thermoplastic |
| gross weight | 45 g |
| number of openers | 2 |
| Number of safety contacts | 2 |
| Number of cable cores | 4 |
| actuator | Magnet |
| actuator switching distance | Actuating magnet BP 6, Sao: 10 mmActuating magnet BP 6, Sar: 22 mmActuating magnet BP 8, Sao: 10 mmActuating magnet BP 8, Sar: 22 mmActuating magnet BP 10, Sao: 20 mmActuating magnet BP 10, Sar: 32 mmActuating magnet BP 15 SS, Sao: 20 mmActuating magnet BP 15 SS, Sar: 32 mm |
| direction of movement | Frontal to the active surface |
| Assured switching distance “ON” S ao | 10 mm20 mm |
| Assured switching distance “OFF” S ar | 22 mm32 mm |
| connection type | Cable |
| length of the line | 1 m |
| core cross-section | 0.25 mm2 |
| core cross-section | 23 AWG |
| Material of the cable sheath | PVC |
| ISO thread of the sensor | M12 |
| Long des Sensors | 38,5 mm |
| Degree of protection | IP67 |
| ambient temperature, min | -25 °C |
| ambient temperature, max | +70 °C |
| Storage and transport temperature, minimum | -25 °C |
| Storage and transport temperature, maximum | +70 °C |
| fatigue strength | 10 … 55 Hz, Amplitude 1 mm |
| shock resistance | 30 g / 11 ms |
| switching voltage, maximum | 100 VAC |
| switching voltage, maximum | 100 VDC |
| switching current, maximum | 0,25 A |
| switching capacity, maximum | 3 W |
| switching frequency, maximum | 5 Hz |
