OMRON-NX-ECC203
Omron-NX-ECC203 NX-series EtherCAT Coupler, 2 ports, 125 µs cycle time, 63 I/O units, max I/O current 10 A, screwless push-in connector, delivered with end cover
| SPECIFICATIONS | |
|---|---|
| I/O system | NX I/O Bus |
| Type of module | Bus coupler |
| IO link master | |
| Suitable for safety functions | |
| SIL according to IEC 61508 | None |
| Communication port(s) | EtherCAT Slave |
| Number of communication ports | 2 |
| Degree of protection (IP) | IP20 |
| Height | 100 mm |
| Width | 46 mm |
| Depth | 80 mm |
| Weight | 170 g |
