WEIDMULLER UR20-4AI-UI-16
Remote I/O module, IP20, 4-channel, Analog signals, Input, Current/Voltage, 16 Bit
| SPECIFICATIONS | |
|---|---|
| Depth | 76 mm |
| Depth (inches) | 2.992 inch |
| Height | 120 mm |
| Height (inches) | 4.724 inch |
| Width | 11.5 mm |
| Width (inches) | 0.453 inch |
| Mounting dimension – height | 128 mm |
| Net weight | 89 g |
| Accuracy | 0.1% FSR |
| Conversion time | 1 ms |
| Individual channel diagnosis | No |
| Internal resistance I | 41.2 Ω |
| Internal resistance U | 100 kΩ |
| Module diagnosis | Yes |
| Number of analogue inputs | 4 |
| Resolution | 16 Bit |
| Response time | < 50 ms |
| Reverse polarity protection | Yes |
| Sensor connection | 2-wire, 3-wire, 3-wire + FE |
| Sensor supply | Yes |
