LEUZE HT46CI/4P-M12 ( 50127061 )
LEUZE HT46CI/4P-M12 Diffuse reflection principle with background suppression Reliable switching in dusty environments.
| SPECIFICATONS | |
|---|---|
| Series | 46C |
| Operating principle | Diffuse reflection principle with background suppression |
| Application | Reliable switching in dusty environments |
| Special version | Dust suppression |
| Black-white error | < 10% up to 700 mm |
| Operating range, white 90% | 0.005 … 2 m |
| Operating range, gray 18% | 0.02 … 1.2 m |
| Operating range, black 6% | 0.05 … 0.7 m |
| Operating range limit | 0.005 … 2 m |
| Adjustment range | 120 … 2,000 mm |
| Light source | LED, Infrared |
| Protective circuit | Polarity reversal protectionShort circuit protectedTransient protection |
| Supply voltage UB | 10 … 30 V, DC, Incl. residual ripple |
| Residual ripple | 0 … 15 %, From UB |
| Open-circuit current | 0 … 30 mA |
| Number of digital switching outputs | 2 Piece(s) |
| Switching frequency | 100 Hz |
| Response time | 5 ms |
| Type of connection | Connector |
| Thread size | M12 |
| Material | Plastic |
| No. of pins | 4 -pin |
| Dimension (W x H x L) | 20.5 mm x 76.3 mm x 44 mm |
| Housing material | Plastic |
| Plastic housing | PC-PBT |
| Lens cover material | Plastic / PMMA |
| Net weight | 60 g |
| Type of fastening | Through-hole mountingVia optional mounting device |
| Compatibility of materials | ECOLAB |
